About 3D Auto Tech – Trusted Sheet Metal Panel Fixture Manufacturer
3D Auto Tech specializes in the design and manufacturing of high-accuracy sheet metal panel checking fixtures for automotive BIW, body panels, and industrial applications.
Our fixtures ensure flawless surface profile verification, dimensional accuracy, and repeatability — essential for quality assurance of formed and welded sheet-metal components.
Why Choose 3D Auto Tech for Sheet Metal Checking Fixtures
- High Accuracy Measurements: Fixtures are engineered for precise profile, contour, and GD&T checks for automotive sheet-metal panels.
- Industrial-Grade Build: Rigid frames and hardened gauging surfaces ensure zero deformation even under heavy inspection cycles.
- Custom Solutions: Fully customized fixtures designed as per vehicle model, panel geometry, and OEM inspection standards.
- BIW & Welding Ready: Suitable for doors, hoods, fenders, roofs, underbody parts, brackets, and complete panel assemblies.
- Cost-Effective Production: Optimized designs ensure long life, reduced maintenance, and affordable inspection systems.
Types of Components Used in Sheet Metal Checking Fixtures
Our sheet-metal panel fixtures are developed using premium components designed for durability, precision, and ease of inspection.
-
Profile & Contour Gauges:
Used for checking panel curvature, profile accuracy, hemming, and flange dimensions with maximum repeatability.
-
Datum Locators:
Precisely machined locators ensure that every part is positioned consistently according to manufacturing datums.
-
Clamping Units:
Pneumatic or manual clamps hold panels securely without deforming the thin sheet metal surface.
-
Base Plates & Welded Frames:
Heavy and stable base plates eliminate flex and vibration during profile scanning or gauging.
Key Features of Our Sheet Metal Fixtures
- Robust Construction: Designed to withstand heavy industrial usage in BIW and press-shop environments.
- Highly Repeatable Measurements: Enables reliable dimensional validation for every production batch.
- CMM Compatible: Designed for offline and inline CMM inspection processes.
- Corrosion & Wear Resistant: Top-grade metals & coatings ensure long operational life.
- Operator-Friendly Layout: Ergonomic design improves handling, reduces inspection time, and minimizes errors.
Applications of Sheet Metal Panel Checking Fixtures
- Automotive BIW Panels: Doors, fenders, roofs, tailgates, hoods, quarter panels.
- Welded Assemblies: Brackets, reinforcements, structural parts, underbody assemblies.
- Industrial Sheet Metal Components: Machine covers, fabricated components, enclosures.
- Stamped Metal Parts: Deep-drawn, press-formed, and laser-cut sheet metal parts.
Why 3D Auto Tech Is the Right Partner for You
At 3D Auto Tech, we deliver inspection fixtures that meet global quality standards, ensuring durability, accuracy, and superior performance for every project.
Our engineering expertise, manufacturing capability, and commitment to customer satisfaction have made us a trusted supplier to leading automotive and industrial brands across India.
Contact us today to get a customized panel checking fixture for your production line.
